Description
High-Performance Acid & Chemical-Resistant Mortar
Furan Resin Mortar is a high-quality acid-resistant and chemical-resistant mortar designed for industrial applications, including bedding and jointing acid-resistant bricks and tiles. Ideal for tanks, drains, floors, foundations, chemical reaction vessels, and neutralization pits, this mortar provides excellent adhesion to concrete, ceramic, and metallic surfaces, ensuring long-lasting durability in harsh environments.
Formulated to resist non-oxidizing acids, alkalies, salts, greases, detergents, and organic solvents, Furan Resin Mortar is perfect for areas exposed to hot or highly concentrated chemical solutions. Its self-hardening, trowelable consistency ensures uniform application, high bond strength, and a leak-proof lining. The mortar also withstands temperatures up to 170°C, making it suitable for chemical tanks and industrial floors where heat resistance is critical.
Key Features
High-performance acid and chemical-resistant mortar
Strong adhesion to ceramic, concrete, and metal surfaces
Resistant to acids, alkalies, and salt solutions
Suitable for industrial tanks, drains, and flooring
Applications
Chemical plants
industrial floors
ETP plants
storage tanks
neutralization pits
industrial pipelines
Chemical Resistance
- Resistant to: Non-oxidizing acids, alkalies, salts, solvents, greases, detergents, oils, and organic acids.
- Carbon-filled Furomor Mortar offers enhanced resistance to hot, concentrated alkalies, hydrofluoric acid, and fluoride salts.
- Maximum service temperature: 170°C
Surface Preparation
- Surfaces must be cement-plastered, dry, clean, and free from dust, dirt, grease, or oil.
- Slightly rough surfaces are required for optimal bonding.
- Maintain required slopes carefully; slopes cannot be adjusted after mortar application.
Setting & Curing
CNSL Resin Mortar is a two-component system consisting of Solution and Powder.
Physical Properties
| Property | Value |
|---|---|
| Mixing Ratio | 3:1 (Powder : Resin by weight) |
| Colour | Black |
| Water Absorption | ≤ 1% |
| Density (cured mortar) | 1.85 – 2.0 g/cc |
| Setting Time | 27 ± 2 minutes |
Mechanical Properties
| Property | Value |
|---|---|
| Working Time (at 30°C) | ≥ 20 minutes |
| Bond Strength | ≥ 10 kg/cm² |
| Compressive Strength | ≥ 350 kg/cm² |
| Flexural Strength | ≥ 75 kg/cm² |
| Water Absorption | Low |
- Solution: 12 months at 30°C (±2°C)
- Powder: 6 months at 30°C (±2°C)
- Store in original, sealed containers in a cool, dry area away from direct sunlight, moisture, and heat.
- Use protective gloves and eyewear during handling.
- Avoid skin contact with uncured material.
- Store components in well-ventilated, dry areas.
